LSPD HQ

Install LSPD HQ on your FiveM server with this guide to resource setup, map coordinates and configuration.

The package contains the map resource and the molo_elevator_lspdhq elevator companion. Install them side by side to use the supplied elevator controls.

Place the folder containing fxmanifest.lua at resources/[maps]/molo_lspdhq/. Keep its name and internal file structure.

Open the outer molo_lspdhq package folder and copy the inner molo_lspdhq resource folder into [maps].

resources/
  [maps]/
    molo_lspdhq/
      fxmanifest.lua
      stream/
      audio/
      npc.lua
    molo_elevator_lspdhq/
      fxmanifest.lua
      client/
        client.lua

1. Back up your existing resource before applying an update.
2. Copy the complete resource folder into the location shown above.
3. Add the startup entry below to server.cfg.
4. Restart the server, then check the startup console for resource errors.
5. Connect and check map loading, room visibility, collision and access before opening the area to players.

Copy molo_elevator_lspdhq into resources/[maps]/molo_elevator_lspdhq/ and start it after the map.

ensure molo_lspdhq
ensure molo_elevator_lspdhq

The map uses the following resource manifest. Keep its streamed files, audio declarations and client scripts together.

fx_version 'bodacious'
game 'gta5'
this_is_a_map 'yes'
lua54 'yes'

client_scripts {
    'npc.lua'
}

data_file('DLC_ITYP_REQUEST')('stream/props/molo_lspdhq_props.ytyp')


dependency '/assetpacks'

data_file 'AUDIO_GAMEDATA' 'audio/molo_lspdhq_game.dat'


files {
  'audio/molo_lspdhq_game.dat151.rel'
}

escrow_ignore {
  'stream/exteriormodels/*'

}

fx_version 'bodacious'
games { 'gta5' }

lua54 'yes'

escrow_asset{
    'client/*',
}

client_scripts{
    'client/*',
}

YTYP file path

The supplied YTYP file is stream/meta/molo_lspdhq_props.ytyp. Set the DLC_ITYP_REQUEST entry in your installation to this path:

data_file 'DLC_ITYP_REQUEST' 'stream/meta/molo_lspdhq_props.ytyp'

Keep dependency '/assetpacks' in the map manifest. This is a manifest requirement; no ensure /assetpacks entry is needed. The manifest declares no ESX or QBCore requirement.

Keep the packaged .dat151.rel audio file and its manifest declarations in place.

The following coordinates identify the technical origin of the map interior (MLO).

local mapOrigin = vector3(269.808075, -380.518555, 43.716476)

For player teleports, set a destination at ground level using your server’s administration tools.

The elevator’s Lobby destination is 69.760857, -387.685120, 48.518864. All three stops are listed in Doors & elevators.

Use these MLO and room identifiers when working with the map’s interior data.

The following door model files are included in the map resource. Use the model names and in-game entity positions when configuring your door-lock resource.

Elevator controls

The supplied molo_elevator_lspdhq script connects Floor -1, Lobby and Roof. Move within 2 metres of a stop, then press Up Arrow for the next stop or Down Arrow for the previous stop.

The script uses controls 188 and 187. Add access restrictions in your server configuration or interaction scripts when assigning role-based access; the supplied elevator script has no job or permission check.

• Keep a backup of the complete resource before each update.
• Match the resource folder name to its ensure entry.
• Keep all supplied streamed files and audio in their original folders.
• Check overlapping map resources when troubleshooting missing or duplicated geometry.
• Use ground-level positions for player teleports and record door positions in game.
• Schedule a full server restart for map updates.

npc.lua clears pedestrians within a radius of 150.0 around 82.02, -394.50, 42.30 every 1000 ms. Account for this area when placing NPCs through other scripts.
